Product introduction
::LEANOMS
A 4 Inch DTH Hammer And Bits are drilling tools commonly used in various industries for rock drilling and excavation purposes. These tools are designed to create boreholes in hard rock formations by utilizing compressed air or other drilling fluids to drive a piston, which impacts the drill bit, breaking the rock.
Common failures
::LEANOMS
Drive Chuck Fracture
| Cause | Precaution or Solution |
| 1. The applied torque and axial pressure are too large. | 1. Reduce feed force and rotation force. |
| 2. The drive chuck is excessively worn due to normal use and breaks normally after exceeding the normal use size. | 2. Frequently check the wear and tear of the drive chuck. If the size exceeds the normal use size, replace the old drive chuck decisively according to the situation. |
| 3. Missing the gasket when replacing the drive chuck. | 3. If the gap between the external cylinder and the drive chuck is found to be too large during the installation process, the gasket should be installed immediately. |
disassembly
LEANOMS
4 Inch DTH Hammer And Bits are typically heat treated to increase their strength, hardness and wear resistance to accommodate the high levels of impact and wear when used in harsh drilling conditions. Heat treatment is a processing method that controls the crystal structure and properties of materials. The following are the steps typically used to heat treat a 4 Inch DTH Hammer And Bits:
1. Heating (pre-heat treatment): First, the materials of the hammer and drill are precisely heated, usually in a high-temperature furnace. This will bring the material to the required temperature to change its crystal structure.
2. Insulation (heat treatment stage): Once the required temperature is reached, the material is kept at that temperature for a period of time, this stage is called "insulation". During this process, the crystal structure begins to change to increase the material's hardness and strength.
3. Cooling (Quenching): Next, the material is brought down from high temperature to room temperature by rapidly cooling it. This process, called quenching, can introduce additional hardness into the crystal structure.
4. Tempering (optional): After quenching, the material may need to be tempered, a process that controls the hardness of the material. By heating and cooling at lower temperatures, you can make the material less brittle while maintaining its hardness.
5. Final inspection and testing: Finally, the heat-treated 4 Inch DTH Hammer And Bits will undergo final quality inspection and testing to ensure that it meets the specifications and has the required mechanical properties and wear resistance.
The goal of heat treatment is to change the structure of the material to improve its performance and ensure that drills and hammers can withstand high levels of impact and friction while maintaining their durability. The specific parameters of the heat treatment process (such as temperature, time and cooling rate) vary depending on the type of material and application, and are therefore often customized by the manufacturer according to the requirements of their product.
product parameters
LEANOMS
Technical Parameters Of 4 Inch DTH Hammer And Bits
