Tricone Bits For Mining

Name: Good Price Tricone Bits For Mining Manufacturers Suppliers Factory
Brand: LEANOMS
SKU: 218629321

Tricone Bits For Mining are versatile drilling tools used in various industries, including mining. They are known for their ability to efficiently drill through a wide range of rock formations encountered in mining operations.

Send Inquiry

Chat Now

PRODUCT INTRODUCTION

Products Description

LEANOMS

Tricone Bits For Mining is one of the main tools for blast hole and well drilling. Its life span and performance whether suitable for drilling or not, that has an great influence about the quality, speed and cost of drilling project.

The rock breakage by the Tricone Bits For Mining which used in mine is working with both the impact of teeth and the shear caused by slippage of the teeth, which bring high rock breaking efficiency and the low operation cost.

The Tricone Bits For Mining developed and manufactured by our company are mainly used for large-scale open-pit mining, such as open-pit coal mines, iron mines, copper mines and molybdenum mines, also the non-metallic mines. With the increasing in variety of type, it's also widely used in quarrying, foundation clearing, hydrogeological drilling, coring, tunneling in railway transportation department and shaft drilling in underground mines.

Materials

LEANOMS.

Tricone Bits For Mining structure：

product-307-393 1. Pin connection
2. Oil tube
3. Shirttail
4. Carbide
5. Roller bearing
6. Ball bearing
7. Thrust plug
8. Thrust block
9. Cone
10. Nozzle
11. Backflow valve
12. Guided sleeve

Normally, the blast hole bit is composed of three shirttails (3) and three intermeshing cones(9) mounted on the journals by bearings(5,6), and guided sleeve. The pin connection or shank(1) is connected with the drill pipe.

bearing structure

LEANOMS

Drillability of mineral rock

Differences in the physical and mechanical properties of rocks lead to varying degrees of difficulty in perforating cones. Some rocks have low strength, high brittleness, and are easily broken. Some rocks are highly abrasive and tough, making them difficult to penetrate. The difficulty of rock drilling is called drillability.

Mastering rock drillability is an important basis for selecting Tricone Bits For Mining types, designing new roller bits, formulating perforation work specifications and estimating perforation costs.

Drillability not only depends on rock properties, but also is related to the size, shape and material of the perforation tool, as well as perforation working conditions and perforation parameters.
