Drill Bit For Water Well





A Drill Bit For Water Well is a specialized tool used in the drilling process to create a borehole or well that reaches underground water sources. These Drill Bit For Water Wells are designed to cut through various types of geological formations, including soil, rock, and gravel, to access the water table below. The choice of Drill Bit For Water Well depends on the specific geological conditions of the area where the well is being drilled.





DTH Hammer slag discharge rate requirements:



Great attention must be paid to the slag discharge ability of the DTH Hammer. Smooth slag discharge from the hole will directly lead to a decrease in the performance of the DTH Hammer, rapid wear of the Drill Bit For Water Well and its accessories, and even cause the drill pipe and DTH Hammerto fall into the hole. The slag discharge capacity is directly related to the slag discharge rate, that is, the rate at which rock slag is blown up from the bottom of the hole.



The slag discharge rate can be defined as the speed of air circulating around the hole at atmospheric pressure. In other words, when calculating the slag discharge rate, the pressure at the bottom of the hole is not included. For normal slag discharge (without foam), the slag discharge rate should exceed 3000ft./min. (914.4m/min).

However, the slagging rate should not exceed 7000ft./min.(2133m/min). The slag discharge rate can be calculated by dividing the air consumption of the central hole by the area of the annulus.



Technical Parameters Of Mission50 DTH Hammer & Bit



Part Description	Part Number
1 Top Sub	LR-M50-01
2 "O" Ring of Top Sub	LR-M50-02
3 Check Valve	LR-M50-03
4 Spring	LR-M50-04
5 Air Distributor	LR-M50-05
6 Internal Cylinder	LR-M50-06
7 Piston	LR-M50-07
8 External Cylinder	LR-M50-08
9 Guided Sleeve	LR-M50-09
10 "O" Ring of Stop Ring	LR-M50-10
11 Stop Ring	LR-M50-11
12 Drive Chuck	LR-M50-12



Bit Shank	Connection Thread	Hole Range	Length	Weight	Working Pressure		Air Consumption (m³/min)
Mission50	API 2 3/8" Reg API 3 1/2" Reg	Φ135-152mm	1106mm	66Kg	10-25Bar		14Bar	24Bar
							10.80	20.07







Your Better Choice Than World-famous Brand in Rock Drilling Products



Skilled Workforce: At our company, we take pride in our team of 850 highly skilled craftsmen. Their dedication to precision and quality is unmatched in the industry.



Cutting-Edge Equipment: We have invested in 350 state-of-the-art manufacturing and testing equipment, ensuring that every piece of drilling equipment we produce meets the highest standards of performance and durability.



Decades of Expertise: With over 20 years of experience in the field of rock drilling, we have accumulated a wealth of knowledge and expertise that enables us to design and manufacture the most reliable and efficient drilling tools.



Global Reach: Our reach extends to over 90 countries worldwide. This extensive international presence is a testament to our commitment to delivering top-notch products and services to clients around the globe.



Innovative Solutions: We continuously innovate our drilling tools to stay ahead of industry trends. Our commitment to research and development ensures that you receive the most cutting-edge solutions for your drilling needs.



Quality Assurance: Quality is at the core of everything we do. Our rigorous quality control processes guarantee that each product leaving our facility is of the highest quality, providing peace of mind to our customers.



Customization: We understand that every drilling project is unique. That's why we offer tailored solutions to meet your specific requirements, whether it's custom tool designs or modifications.



Competitive Pricing: Despite our unwavering commitment to quality, we offer competitive pricing, making our products accessible to a wide range of customers without compromising on performance.



Reliability: Our track record of delivering reliable drilling equipment speaks for itself. Count on us to provide tools that perform consistently under the most challenging conditions.



Customer-Centric Approach: We prioritize our customers' satisfaction above all else. Our dedicated customer support team is always ready to assist you with any inquiries or concerns, ensuring a seamless experience from start to finish.
